KEY FEATURES |
IO | Digital Input: 4, Digital Output: 2, ADC: 1, 1-Wire: 1, RS-232: 1 |
GNSS & LTE Antenna
| Internal High Gain Antenna
|
Indicators
| 3 LED's (Power, LTE, GNSS)
|
USB | 2.0 Micro USB |
SIM
| Micro SIM
|
Memory
| 6,000 Log Packets |
Bluetooth | BLE 5.0
|
POWER |
Voltage Range | 8-36V DC |
Battery | 250mAh Li-Po 3.7V |
NAVIGATION |
GNSS | GPS, GLONASS, BeiDou |
Channels | 24 Tracking / 65 Acquisition Channel |
Horizontal Position Autonomous | < 2.5m |
SBAS | Supported |
2 DRMS, Vertical | ± 5m
|
Tracking Sensitivity | -160dBm |
Re acquisition Sensitivity | -154dBm |
Velocity
| < 0.1m/s
|
Hot Start
| < 1 sec
|
Warm Start
| < 30 sec
|
Cold Start
| < 40 sec
|
CELLULAR NETWORK |
Band | 4G: B1,B3,B5,B8,B34,B38,B39,B40,B41; 2G: 850/900/1800/1900 MHz |
RF Power | EGSM900: Class 4(33dBm ±2dB) , DCS1800: Class 1(30dBm ±2dB) , LTE Power Level 3(23dBm ±2.7dB) |
Coding Scheme | CS 1, 2, 3, 4 |
SMS
| Point-to-point MO & MT, SMS cell broadcast
|
OPERATING ENVIRONMENT |
Working Current | Sleep Mode < 25mA, Active Mode < 100mA |
Operating Temperature | -20 °C to +60 °C (With Battery), -30 °C to +80 °C (Without Battery)
|
Humidity | 5% to 95% non-condensing at +40°C |
Ingress Protection Rating
| IP54 |
