Bluetooth connectivity expands usage scenarios with beacons, humidity, and temperature sensors.
Seamless WiFi connectivity for real-time data access and remote control.
High voltage range enables extended operation and enhanced performance efficiency.
| MPU | SAM9X60D1G |
| Wireless Interface | 802.11ac, Bluetooth v5.1, LTE,LoRa |
| RAM | 1Gbit integrated DDR2,64 kB internal SRAM |
| Flash Storage | 4Gb onboard NAND flash |
| Serial | USB, Ethernet, Dual CAN 2.0 |
| Wi-Fi | 802.11ac with 2x2 MU-MIMO |
| Bluetooth | Bluetooth 5.1 |
| LTE | Cat 1 FDD and TDD, Support 1.4/3/5/10/15/20 MHz RF bandwidth, Support MIMO in DL direction, FDD: Max 10 Mbps (DL), Max 5 Mbps (UL), TDD: Max 896 Mbps (DL), Max 3.1 Mbps (UL) |
| Channel | 8 |
| Frequency Band | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923 |
| Sensitivity | -140dBm Sensitivity @292bps |
| Output Power | 27dBm Max |
| Protocol | V1.0 Class A/Class B/Class C and V1.0.2 Class A/Class B/Class C |
| Standards | WEP, WPA, WPA2 |
| Dynamic | 802.1X Extensible Authentication Protocol Types (EAP-FAST, EAP-TTLS, PEAP-GTC, PEAP- MSCHAPv2, LEAP) |
| Chain of Trust Architecture | Secure boot, hardware root-of-trust, encrypted file systems, cryptographic accelerator |
| IoT Platform Support | Amazon Web Services (AWS) with integrated support for AWS IoT Greengrass |
| Provisioning | Connect to Wi-Fi with companion smartphone app for Android and iOS |
| Dimensions | 87x102x30mm (L X B X H) |
| Ethernet | 1 x RJ45 port, 10/100/1000 Mbps |
| Status LEDs | 1 x charging led, 1x power led ,1x MPU_STATUS, 1X 1PPS, 1x Module_VCC ,1 x NRF Status |
| SIM | 1 x Internal SIM slot (Mini SIM – 2FF) |
| Power | 1 x 6 interface connector socket |
| Antennas | 4 x SMA connector |
| Operating Temperature | -30° to +85°C (-22° to +185°F) |
| Relative Humidity | 0-95% Non-condensing |
| Connector | 1 x 6 interface connector socket, 1 x USB TYPE C, 1 x USB TYPE A |
| Input voltage range | 9-90V |
| PoE (passive) | Possibility to power up through ETH port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 90 VDC |
| Power consumption | Idle: < 0.25 W, Max: < 3.3 W |
| CAN protocol | DUAL CAN 2.0 |
| Ethernet | 1 x ETH port, 10/100/1000 Mbps, compliance with IEEE 802.3 |
A sophisticated solution for remotely managing devices, featuring a multi-tiered account structure. Establish intelligent groups and schedules to automate firmware and configuration updates.
Know More
A cutting-edge device configuration solution equipped with automated software updates. Optimize device usage by leveraging tooltips and a device wizard for helpful guidance, accelerating the configuration process with search and filters.
