High-efficiency video compression for clear streaming with reduced bandwidth usage
Seamless WiFi connectivity for real-time data access and remote control
Equipped with a built-in high sensitivity microphone for clear audio capture in any environment.
| Dimension | 125.6 * 86.6 * 46.9 mm |
| Weight | 159 g |
| Weight | 159 g |
| Weight | 159 g |
| Working temperature | -20 °C to +70 °C |
| Typical power consumption | Less than 10W |
| Storage | 1080P 600MB/Hour/CH H.265, 1080P 1200MB/Hour/CH H.264 |
| Power Input | 9V-32V |
| Upgrading method | USB disk, SD card, Wireless network |
| Upgrading mode | Manual/ Automatic/ Remote |
| Audio bit rate | 8Kb/s |
| Video search | Searchable by channel, type of recording |
| Video Method | Automatic/Alarm |
| Recording Method | Audio & Video synchronized recording |
| Audio Compression | G.711A, G.711U, G.726 |
| Recording Quality | Class 1-6 optional |
| Video Compression | H.265/ H.264 |
| Image Resolution | 1080P/ 720P/ 960H/ D1/ CIF |
| Password security | User password management |
| Operating interface | Configuration via maintenance tool |
| Operating language | English |
| Operating System | Embedded Linux OS |
| Indicators | PWR/RUN two color light |
| USB Port | MICRO USB Port |
| SIM | Micro SIM |
| SD Card | Supported |
| Audio Output | Built-in 2W speaker |
| Audio Input | Built-in MIC |
| AV Input | 2CH Built-in 1080P camera, 1CH 4pin BMW head port |
| Ignition Input | 1 ACC Signal |
| Memory | 512 Gb |
| GNSS | Built-in ceramic antenna, GPS + BD + GLONASS |
| Wireless | 4G Support |
| WiFi | Frequency 2.4GHz |
| GNSS | Built-in ceramic antenna, GPS + BD + GLONASS |
| Wireless | 4G Support |
| WiFi | Frequency 2.4GHz |
| GNSS | Built-in ceramic antenna, GPS + BD + GLONASS |
| Wireless | 4G Support |
| WiFi | Frequency 2.4GHz |
