Seamless WiFi connectivity for real-time data access and remote control
Provides accurate real-time location data for efficient vehicle tracking and management.
Captures clear audio alongside video for comprehensive monitoring and incident review.
| Video Input | 4 AHD channels |
| Video Output | 1 x VGA, 1 x CVBS |
| Audio Input | Supported (via aviation A / V interface) |
| Audio Output | Supported (via aviation A / V interface) |
| Recording Resolution | Up to 1080p |
| Compression Format | H.264/H264+/H265/H265+ |
| Preview Display | Real-time preview supported |
| GNSS | GPS/BD |
| 4G Band | 3G/4G- CDMA/EVDO/GPRS/WCDMA/FDD LTE/TDD LTE |
| Wi-Fi | Support 802.11b/g/n, frequency 2.4ghz |
| Ethernet Port | 1 x 6 pin aviation to RJ45 (10M/100M), 500mA@12V (Optional) |
| Communication Ports | UART-1 LVTTL Level |
| Power Input | 8-36V DC |
| Output for Cameras | 5V 30mA |
| Power Consumption | 10W without peripherals, 18 W maximum consumption @12v 1.5A @24V 0.75A |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | 40°C to +85°C |
| Humidity Range | 10% – 95% |
| Internal Storage | 1 x 2.5" HDD (up to 2TB) |
| External Storage | 1 x SD/TF Card (up to 256GB) |
| File Backup | USB or Network |
| Storage Capacity | 1080P: 0.75G/ hour/ channel, 720P: 0.58G/ hour/ channel, 960H: 0.37G/ hour/ channel |
| Overwrite Function | Yes |
| Dimensions | 162 x 153 x 52 mm |
| Video Streaming | Live video streaming with GPS via 4G and Wi-Fi |
| Location Tracking | Real-time GPS tracking supported |
| Wireless Connectivity | 4G LTE, GPS, and Wi-Fi supported |
| Data Synchronization | Automatic via 4G/Wi-Fi with location tagging |
| Remote Playback & Download | Supported via 4G and Wi-Fi |
| Firmware Updates | Remote via FOTA |
| Cloud CMS Integration | Supported |
| Alarm & Event Alerts | Alerts sent via 4G/Wi-Fi with GPS tagging |
| Driver Behavior Monitoring | Available with CMS platform |
