Sustained power for prolonged operational efficiency, minimizing downtime and enhancing reliability.
The IP67-rated casing ensures robust protection against dust and water immersion.
Bluetooth connectivity expands usage scenarios with beacons, humidity, and temperature sensors.
| Model | CR2032 |
| Type | Lithium, Manganese Dioxide (Li/ MnO2) |
| Total Capacity | 225mAh |
| Replaceable | Yes |
| Battery Life (Tx = 2 dBm; interval: 5 s) | 1 Year |
| Battery Life (Tx = 2 dBm; interval: 10 s) | 1 Year |
| Battery Life (Tx = 2 dBm; interval: 30 s) | 1.5 Years |
| Microcontroller | NRF 52832 |
| Quartz Crystals | 32.768 kHz, 32 MHz |
| Bluetooth Operating Frequency | 2.402 - 2.480 GHz |
| Bluetooth Antenna Gain (Peak) | -2.58 dBi |
| Bluetooth | BLE 5.0 |
| Range | 50 m |
| Transmission Power Levels | Up to 8 dBm |
| Sensitivity | -88 dBm |
| Functionalities | Beacon ID, LED, Temperature & storing temperature data, Humidity, Accelerometer, Gas sensing, Hibernate |
| Dimensions | Ø 36mm X 12mm |
| Weight | 12.86 grams |
| Internal Memory Temperature Records | 20,000 |
| Temperature Sensing Range | -40°C to 85°C |
| Accuracy Class | 0.3 |
| Laboratory Calibrated Temperature Sensor | Yes |
| Humidity (Non-Condensing) | From 0% to 100% |
| Operational Temperature | -20°C / +60°C (-4°F / +140°F) |
| Protection | IP67 |
| Mounting | Two slots for Wristband/ Neckband |
| Atlanta | Yes |
