Securely attach and relocate with ease using strong magnetic mounting capabilities.
Receive instant notifications of unauthorized access or tampering attempts for enhanced security.
The IP67-rated casing ensures robust protection against dust and water immersion.
| GNSS Antenna | Internal High Gain GNSS |
| LTE Antenna | Internal High Gain LTE |
| Indicators | 4 LED's (MCU, Charging, LTE, GNSS) |
| SIM | Micro SIM |
| USB | C-Type |
| Memory | 10,000 Log Packets |
| Mounting | Magnetic Mounting |
| GNSS | GPS, GLONASS, GALILEO, BeiDou, QZSS |
| Channels | 47 Tracking Channels |
| Horizontal Position Autonomous | 1.5m CEP |
| Tracking Sensitivity | -166 dBm |
| Velocity | 0.1m/s |
| Hot Start | 1 sec |
| Warm Start | 25 sec |
| Cold Start | 28 sec |
| Re acquisition Sensitivity | -159dBm |
| Technology | LTE CAT1, GSM |
| 4G Band | EG915U-CN(900/1800 MHz), EG915U-EU(850/900/1800/1900 MHz) |
| RF Power | EG915U-CN(EGSM900: Class 4 (33 dBm ±2 dB),DCS1800: Class 1 (30 dBm ±2 dB), LTE-FDD: Class 3 (23 dBm ±2 dB), LTE-TDD: Class 3 (23 dBm ±2 dB)) EG915U-EU(GSM850/EGSM900: Class 4 (33 dBm ±2 dB), DCS1800/PCS1900: Class 1 (30 dBm ±2 dB), LTE-FDD: Class 3 (23 dBm ±2 dB)) |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | Point to point MO & MT, SMS cell broadcast |
| 2G Band | EG915U-CN(B1,3,5,8,34,38,39,40,41), EG915U-EU(B1,3,5,7,8,20,28) |
| External Adapter | 5V DC, 1A Adapter |
| Battery | 10000mAh Li-Po 3.7V |
| Working Current | Sleep Mode < 5mA, Active Mode < 125mA |
| Operating Temperature | -10 °C to +60 °C (With Battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Ingress Protection Rating | IP67 |
| Dimensions | 108 x 100 x 46 mm (L x B x H) |
| Configuration and firmware update | FOTA |
| SMS | Configuration, Debug |
| GPRS commands | Configuration, Debug |
