The IP67-rated casing ensures robust protection against dust and water immersion.
Receive instant notifications of unauthorized access or tampering attempts for enhanced security.
Sustained power for prolonged operational efficiency, minimizing downtime and enhancing reliability.
| GNSS Antenna | Internal High Gain GNSS |
| LTE Antenna | Internal High Gain LTE |
| Indicators | 4 LED's (MCU, Charging, GSM, GPS) |
| SIM | Micro SIM |
| USB | C-Type |
| Memory | 10,000 Log Packets |
| GNSS | GPS, GLONASS, BeiDou,QZSS |
| Channels | 47 Tracking Channels |
| Horizontal Position Autonomous | 1.5m CEP |
| Tracking Sensitivity | -166 dBm |
| Hot Start | 1 sec |
| Warm Start | 25 sec |
| Cold Start | 28 sec |
| SBAS | Supported |
| Re-acquisition Sensitivity | -159 dBm |
| Velocity | 0.1 m/s |
| Technology | LTE CAT1, GSM |
| 4G Band | EG915U-CN(B1,3,5,8,34,38,39,40,41), EG915U-EU(B1,3,5,7,8,20,28) |
| RF Power | EG915U-CN(EGSM900: Class 4 (33 dBm ±2 dB),DCS1800: Class 1 (30 dBm ±2 dB), LTE-FDD: Class 3 (23 dBm ±2 dB), LTE-TDD: Class 3 (23 dBm ±2 dB)) EG915U-EU(GSM850/EGSM900: Class 4 (33 dBm ±2 dB), DCS1800/PCS1900: Class 1 (30 dBm ±2 dB), LTE-FDD: Class 3 (23 dBm ±2 dB)) |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | Point to point MO & MT, SMS cell broadcast |
| 2G Band | EG915U-CN(900/1800 MHz), EG915U-EU(850/900/1800/1900 MHz) |
| External Adapter | 5V DC, 1A Adapter |
| Battery | 5000mAh Li-Po 3.7V |
| Operating Temperature | -10 °C to +60 °C (With Battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Working Current | Sleep Mode < 1mA, Active Mode < 125mA |
| Ingress Protection Rating | IP67 |
| Dimensions | 108 x 100 x 33 mm (L x B x H) |
| Configuration and firmware update | FOTA |
| SMS | Configuration, Debug |
| GPRS commands | Configuration, Debug |
