KEY FEATURES |
IO | Digital Input: 2, Digital Output: 1, Analog Input: 1 |
GNSS & GPS Antenna
| Internal High Gain Antenna
|
Indicators
| 3 LED's (Power, GSM, GPS)
|
USB | 2.0 Micro USB |
SIM
| Micro SIM
|
Memory
| 6,000 Log Packets |
POWER |
Voltage Range | 8-36V DC |
Battery | 250mAh Li-Po 3.7V |
NAVIGATION |
GNSS | GPS, GLONASS, AGPS, QZSS, GAGAN |
Channels | 22 Tracking / 66 Acquisition Channel |
Horizontal Position Autonomous | < 2.5m |
SBAS | Supported |
2 DRMS, Vertical | ± 5m
|
Tracking Sensitivity | -165dBm |
Re acquisition Sensitivity | -160dBm |
Velocity
| < 0.1m/s
|
Hot Start
| < 1 sec
|
Warm Start
| < 30 sec
|
Cold Start
| < 35 sec
|
CELLULAR NETWORK |
Band | 2G Band: 850/900/1800/1900MHz |
RF Power | Class 4 (2W@850/900MHz), Class 1 (1W@1800/1900MHz) |
Coding Scheme | CS 1, 2, 3, 4 |
SMS
| Point-to-point MO & MT, SMS cell broadcast
|
OPERATING ENVIRONMENT |
Working Current | Sleep Mode < 5mA, Active Mode < 125mA |
Operating Temperature | -20 °C to +60 °C (With Battery), -30 °C to +80 °C (Without Battery)
|
Humidity | 5% to 95% non-condensing at +40°C |
Ingress Protection Rating
| IP54 |
