The SOS button instantly alerts emergency contacts, providing your real-time location for quick assistance.
Sustained power for prolonged operational efficiency, minimizing downtime and enhancing reliability.
Higher GNSS accuracy ensures precise location tracking and navigation capabilities.
| Digital Input | 1+1* |
| SIM | Micro SIM |
| Indicators | 4 LED's (Power, Charging, GSM, GPS) |
| Digital Output | 1 |
| GNSS Antenna | Internal High Gain GNSS |
| GSM Antenna | Internal High Gain GSM |
| Memory | 15,000 Log Packets |
| Peripheral | SOS/Panic Button |
| GNSS | GPS, GAGAN, QZSS, BeiDou |
| Channels | 32 tracking channels, 96 capture channels, 210 PRN channels |
| Horizontal Position Autonomous | < 2.5m CEP |
| SBAS | Supported |
| Tracking Sensitivity | -158 dBm |
| Re-acquisition Sensitivity | -156 dBm |
| Velocity | 0.1m/s |
| Hot Start | < 1 sec |
| Warm Start | < 10 sec |
| Cold Start | < 35 sec |
| Technology | GSM |
| 2G Band | 850/900/1800/1900 MHz |
| RF Power | Class 4 (2W@850/900MHz), Class 1 (1W@1800/1900MHz) |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | Text |
| Data | GPRS Multislot Class |
| Voltage Range | 8-36V DC |
| Battery | 250mAh Li-Po 3.7V |
| Working Current | Sleep Mode < 5mA, Active Mode < 100mA |
| Operating Temperature | -20 °C to + 60 °C (With Battery), -30 °C to +75 °C (Without Battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Dimensions | 91 x 52 x 19.5 mm (L x B x H) |
| Weight | 65 g |
| Sensors | Motion Sensor |
| Scenarios | Over speeding, DOUT, Idling data |
| Configuration and firmware update | FOTA, SMS, GPRS Commands |
| SMS | Configuration, Events, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time Synchronization | GPS |
| Ignition detection | Digital input 1 |
