The SOS button instantly alerts emergency contacts, providing your real-time location for quick assistance.
Bluetooth connectivity expands usage scenarios with beacons, humidity, and temperature sensors.
The IP54-rated casing ensures robust protection against dust and water immersion.
| USB | USB C-type |
| GNSS Antenna | Internal High Gain GNSS |
| LTE Antenna | Internal High Gain LTE |
| Indicators | 3 LED's (Battery charging, GSM, GPS) |
| SIM | Nano SIM |
| Audio Alert | Buzzer |
| Memory | 32Mb Flash memory (10000 log packets) |
| Mounting | Magnet/ Clamp/ Velcro |
| GNSS | GPS, GLONASS, GALILEO, QZSS |
| GPS Receiver | 72-channel u-blox M8 engine GPS L1C/A, SBAS L1C/A, QZSS L1C/A, QZSS L1C/A , GLONASS L1OF, BeiDou B1l, Galileo EIB |
| Horizontal Position Autonomous | < 2.5m CEP |
| Tracking Sensitivity | -167 dBm |
| Reacquisition Sensitivity | -160 dBm |
| Velocity Accuracy | 0.05 m/s |
| Hot Start | < 1 sec |
| Warm Start | < 3 sec |
| Cold Start | < 26 sec |
| Cold Start | < 26 sec |
| Technology | LTE |
| 4G Band | EU: B1, B3, B7, B8, B20; NA: B2, B4, B5, B12, B13 |
| 3G Band | NA: B2,B5 |
| 2G Band | EU: 900/1800 MHz |
| RF Power | Class 4 (2W@850/900 MHZ), Class 1 (1W@1800/1900 MHz) |
| Coding Scheme | CS 1, 2, 3, 4 |
| Data Support | SMS (Text/Data) |
| Data Transfer | Downlink up to 10 Mbps, Uplink up to 5 Mbps |
| External Adapter | 5V DC, 1A Adapter |
| Battery | 2600mAh Li-Po 3.7V |
| Working Current | Sleep Mode < 10mA, Active Mode < 250mA @ 3.7V |
| Operating Temperature | -10 °C to +60 °C (With Battery) |
| Battery charge temperature | 0 °C to +45 °C |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Ingress Protection Rating | IP54 |
| Battery discharge temperature | -10 °C to +60 °C |
| Dimensions | 119X91X34 mm |
| Weight | 200 g (Approx) |
| Sensors | Motion wake up, Periodic tracking on stop / on move |
| Scenarios | Single / Custom sleep mode |
| Configuration and firmware update | FOTA Web, FOTA, Atlanta Configurator (USB) |
| SMS | Configuration, Events, Debug |
| GPRS commands | Configuration, Debug |
| Regulatory | NA: FCC,PTCRB EU: CE |
