Securely attach and relocate with ease using strong magnetic mounting capabilities.
Receive instant notifications of unauthorized access or tampering attempts for enhanced security.
The IP67-rated casing ensures robust protection against dust and water immersion.
| GNSS Antenna | Internal High Gain |
| LTE Antenna | Internal High Gain |
| Indicators | 4 LED's (MCU, Charging, LTE, GNSS) |
| SIM | Micro SIM |
| USB | C-Type |
| Memory | 10,000 Log Packets |
| Mounting | Magnetic Mounting |
| GNSS | GPS, QZSS, BeiDou, GAGAN, GLONASS |
| Channels | 22 Tracking / 66 Acquisition Channel |
| Horizontal Position Autonomous | < 2.5m CEP |
| Tracking Sensitivity | -161dBm |
| Velocity | 0.1m/s |
| Hot Start | < 1 sec |
| Warm Start | < 30 sec |
| Cold Start | < 35 sec |
| Technology | LTE |
| 4G Band | B1/B3/B5/B8/B34/B39/B40/B41 |
| RF Power | Class 4 (2W@850/900MHz), Class 1 (1W@1800/1900MHz) |
| Data Transfer | GPRS Multi-Slot Class 12 |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | SMS (text/data) |
| External Adapter | 5V DC, 1A Adapter |
| Battery | 10000mAh Li-Po 3.7V |
| Working Current | Sleep Mode < 5mA, Active Mode < 125mA |
| Operating Temperature | -20 °C to +60 °C (With Battery), -30 °C to +80 °C (Without Battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Ingress Protection Rating | IP67 |
| Dimensions | 108 x 100 x 46 mm (L x B x H) |
| Weight | 420g |
| Scenarios | Motion wake up, Periodic tracking on stop / on move |
| Sensors | Single / Custom sleep mode |
| Conguration and rmware update | FOTA Web, FOTA, Atlanta Configurator (USB) |
| SMS | Configuration, Events, Debug |
| GPRS commands | Configuration, Debug |
