The IP67-rated casing ensures robust protection against dust and water immersion.
Extended uptime, minimizing interruptions, enhancing operational reliability and efficiency
Instant emergency alert button for quick assistance and immediate response
| Operating Temperature | -20 °C to +60 °C (With Battery), -30 °C to +75 °C (Without Battery) |
| Working Current | Active mode:- 75mA average |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Ingress Protection Rating | IP67 |
| Battery | 1,000mAh Li-Po 3.7V |
| External Adapter | 5V DC, 1A Adapter |
| SMS | SMS (text/data) |
| Coding Scheme | CS 1, 2, 3, 4 |
| RF Power | Class 4 (2W@850/900MHz), Class 1 (1W@1800/1900MHz) |
| Technology | GSM |
| 2G Band | 850/900/1800/1900 MHz |
| Cold Start | < 15 sec |
| Warm Start | < 5 sec |
| Hot Start | < 1 sec |
| Velocity | 0.1m/s |
| Re-acquisition Sensitivity | -160 dBm |
| Tracking Sensitivity | 163 dBM |
| SBAS | Supported |
| Horizontal Position Autonomous | <2.5m CEP |
| GNSS | GPS, BeiDou |
| Peripheral | SOS Button |
| Memory | 2,000 Log Packets |
| SIM | 4FF Plastic SIM(NANO SIM) |
| Indicators | 5 LEDs (GSM, GPS, CPU, Power, Charging) |
| USB | USB C-type |
| GSM Antenna | Internal High Gain GNSS |
| GNSS Antenna | Internal High Gain GNSS |
| Dimensions | 55 X 38 X 25 mm (L x B x H) |
| Weight | 56 g |
| Configuration and firmware update | FOTA |
| SMS | Configuration, Debug |
| GPRS Commands | Configuration, Debug |
