Seamlessly connect for real-time vehicle data monitoring and diagnostics with built-in CAN port.
High voltage range enables extended operation and enhanced performance efficiency.
Bluetooth connectivity expands usage scenarios with beacons, humidity, and temperature sensors.
| Digital Input | 2 |
| Digital Output | 2 |
| Analog Input | 1 |
| 1-RPM / 1-Wire | 1 |
| CAN | 1 |
| GNSS Antenna | Internal High Gain GNSS |
| GSM Antenna | Internal High Gain GSM |
| Indicators | 4 LED's (Charging,Power, GSM, GPS) |
| SIM | Micro SIM |
| USB | 2.0 Micro USB |
| Memory | 32 Mb (17,000 packets on single IP) |
| CAN Protocol Support | All legislated OBD-II Protocols, Non-Legislated OBD Protocols & Heavy-Duty |
| GNSS | GPS, GAGAN, QZSS, BeiDou |
| Receiver | 32 tracking channels, 96 capture channels, 210 PRN channels |
| Horizontal Position Autonomous | < 2.5m CEP |
| SBAS | Supported |
| Tracking Sensitivity | -158dBm |
| Re acquisition Sensitivity | -156dBm |
| Velocity | 0.1m/s |
| Hot Start | < 1sec |
| Warm Start | 10sec |
| Cold Start | < 35sec |
| Technology | GSM |
| 2G Band | 850/900/1800/1900 MHz |
| RF Power | Class 4 (2W@850/900MHz), Class 1 (1W@1800/1900MHz) |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | Text |
| Voltage Range | 9-90V DC |
| Battery | 250mAh Li-Po 3.7V |
| Specification | BLE 5.0 |
| Supported Peripherals | Universal BLE sensors support, Beacons |
| Working Current | Sleep Mode <25mA, Active Mode <180mA |
| Operating Temperature | -20 °C to +60 °C (With Battery), -30 °C to +75 °C (Without Battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Ingress Protection Rating | IP54 |
| Dimensions | 88x45x15 mm (LxBxH) |
| Weight | 110 g (Approx) |
| Sensors | Accelerometer Supported |
| Scenarios | Overspeeding, DOUT, Unplug detection (Other alerts like excessive Idling, towing, geofence can be integrated) |
| Configuration and firmware update | FOTA, FOTA Web, Configuration over USB & BLE |
| SMS | Configuration, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time Synchronization | GPS |
| Ignition detection | Digital Input 1 |
