Advanced CAT-1, CAT-M1, NB-2 connectivity with 2G fallback ensures uninterrupted operations.
Efficiently monitor vehicle data and performance through seamless connectivity with with built-in CAN port.
High voltage range enables extended operation and enhanced performance efficiency.
| Battery storage temperature | -20 °C to +45 °C for 1 month, -20 °C to +35 °C for 6 months |
| Operating Temperature | -20 °C to +60 °C (With Battery), -30 °C to +75 °C (Without Battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Ingress Protection Rating | IP67 |
| Battery charge temperature | 0 °C to +45 °C |
| Battery discharge temperature | -20 °C to +60 °C |
| Digital Input | 4 |
| Digital Output | 4 |
| Analog Input | 2 |
| RS232/RS485 | 1/1* |
| CAN | 2 |
| 1-Wire | 1 |
| GNSS Antenna | Internal High Gain GNSS |
| LTE Antenna | Internal High Gain LTE |
| Indicators | 4 LEDs (Power, LTE, GPS, Charging) |
| SIM | Micro SIM or eSIM |
| USB | 2.0 Micro USB |
| Memory | 64Mb |
| GNSS | GPS, GLONASS, GALILEO, BeiDou, QZSS |
| Channels | 47 Tracking Channels |
| Horizontal Position Autonomous | 1.5m |
| SBAS | Supported |
| Tracking Sensitivity | -166 dBm |
| Re acquisition Sensitivity | -159 dBm |
| Velocity | 0.1 m/s |
| Hot Start | 1 sec |
| Warm Start | 2 sec |
| Cold Start | 15 sec |
| Technology | LTE CAT1, GSM |
| 4G Band | EG915U-CN: LTE FDD: B1/B3/B5/B8, LTE TDD: B34/B38/B39/B40/B41; EG915U-EU: LTE-FDD: B1/ 3/ 5/ 7/ 8/ 20/ 28; EG915U-NA: LTE-FDD: B2/3/4/5/7/8/28/66 |
| 2G Band | EG915U-CN(900/1800 MHz), EG915U-EU(850/900/1800/1900 MHz), EG915U-NA(850/900/1800/1900 MHz) |
| RF Power | EG915U-CN(EGSM900: Class 4 (33 dBm ±2 dB),DCS1800: Class 1 (30 dBm ±2 dB), LTE-FDD: Class 3 (23 dBm ±2 dB), LTE-TDD: Class 3 (23 dBm ±2 dB)); EG915U-EU & NA(GSM850/EGSM900: Class 4 (33 dBm ±2 dB), DCS1800/PCS 1900: Class 1 (30 dBm ±2 dB), LTE-FDD: Class 3 (23 dBm ±2 dB)) |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | Point to point MO & MT, SMS cell broadcast |
| Voltage Range | 9-90V DC |
| Battery | 1000mAh Li-Po 3.7V |
| Specification | BLE 5.0 |
| Supported Peripherals | Temperature & Humidity sensor, Universal BLE sensors support, Beacons |
| Dimensions | 90x112x41 mm (LxBxH) |
| Weight | 210 g |
| Sensors | 3D Accelerometer &3D Gyroscope |
| Scenarios | Overspeed detection, Manual Geofence, Unplug detection, Harsh Acceleration, Harsh Braking, Rush turning, Cabinet tamper detection, Battery low, Parameter setting alerts, SOS alerts |
| Sleep modes | Deep Sleep |
