High voltage range enables extended operation and enhanced performance efficiency
Higher GNSS accuracy ensures precise location tracking and navigation capabilities.
Monitor battery health and optimize performance through advanced analytics for efficient electric vehicle operation.
| Digital Input | 2 |
| Digital Output | 1 |
| ADC | 1 |
| GNSS Antenna | Internal High Gain GNSS |
| GSM Antenna | Internal High Gain GSM |
| Indicators | 3 LED's (Power, GSM, GNSS) |
| SIM | Micro SIM |
| Memory | 1800 Log Packets |
| GNSS | GPS, BeiDou |
| Horizontal Position Autonomous | < 2.5m CEP |
| SBAS | Supported |
| Tracking Sensitivity | -163 dBm |
| Re acquisition Sensitivity | -160 dBm |
| Velocity | 0.05 m/s |
| Hot Start | < 1 sec |
| Warm Start | < 3 sec |
| Cold Start | < 26 sec |
| Technology | GSM |
| 2G Band | 850/900/1800/1900 MHz |
| RF Power | Class 4 (2W@850/900MHz), Class 1 (1W@1800/1900MHz) |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | Point to point MO & MT, SMS cell broadcast |
| Voltage Range | 9-90V DC |
| Battery | 250mAh Li-Po 3.7V |
| Working Current | Sleep Mode < 25mA, Active Mode < 110mA |
| Operating Temperature | -20 °C to +70 °C (With Battery), -30 °C to +80 °C (Without Battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Dimensions | 90 x 48 x 17.5 mm (L x B x H) |
| Weight | 75 g (Approx) |
| Sensors | Motion Sensor |
| Scenarios | Over Speed Detection, Unplug Detection |
| Configuration and firmware update | FOTA Web, FOTA, Configuration Tool(Custom Connector) |
| SMS | Configuration, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time Synchronization | GPS |
| Fuel monitoring | LLS(Analog) |
| Ignition detection | Digital Input |
