The IP54-rated casing ensures robust protection against dust and water immersion.
Temperature sensor monitors vehicle temperature for real-time tracking and optimal operation
i-Button enhances vehicle security with advanced identification and tracking capabilities.
| Digital Input | 4 |
| Digital Output | 1 |
| Analog Input | 1 |
| 1-Wire | 1 |
| GNSS Antenna | Internal High Gain GNSS |
| GSM Antenna | Internal High Gain GSM |
| Indicators | 4 LED's (Power, GSM, GNSS, Charging) |
| SIM | Micro SIM |
| USB | 2.0 Micro USB |
| Memory | 6,000 Log Packets |
| Peripheral | i-button, 1-Wire Temperature Sensor |
| GNSS | GPS, AGPS, QZSS, GAGAN |
| Channels | 22 Tracking / 66 Acquisition Channel |
| Horizontal Position Autonomous | 2.5m CEP |
| SBAS | Supported |
| Tracking Sensitivity | -165 dBm |
| Re acquisition Sensitivity | -160 dBm |
| Velocity | 0.1m/s |
| Hot Start | <1 sec |
| Warm Start | 30 sec |
| Cold Start | 31 sec |
| Technology | GSM |
| 2G Band | 850/900/1800/1900 MHz |
| RF Power | Class 4 (2W@850/900MHz), Class 1 (1W@1800/1900MHz) |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | MO & MT, SMS cell broadcast, Text & PDU mode |
| Voltage Range | 8-36V DC |
| Battery | 250mAh Li-Po 3.7V |
| Working Current | Active Mode < 120mA |
| Operating Temperature | -20°C to +60°C (With Battery), -30°C to +75°C (Without Battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Ingress Protection Rating | IP54 |
| Dimensions | 100 x 54 x 17 mm (L x B x H) |
| Weight | 75 g |
| Sensors | Accelerometer |
| Scenarios | Over speeding, DOUT, Unplug detection |
| Configuration and firmware update | FOTA, Configuration over USB |
| SMS | Configuration, Events, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time Synchronization | GPS |
| Fuel monitoring | LLS(Analog) |
