Bluetooth connectivity expands usage scenarios with beacons, humidity, and temperature sensors.
High voltage range enables extended operation and enhanced performance efficiency.
Secure your wheels with instant lock/unlock control, ensuring enhanced vehicle safety and convenience.
| Digital Output | 2 |
| GNSS Antenna | Internal High Gain GNSS |
| GSM Antenna | Internal High Gain GSM |
| Indicators | 4 LEDs (Power, Charging, GSM, GNSS) |
| USB | 2.0 Micro USB |
| SIM | Micro SIM(3FF) |
| Memory | 17,000 Log Packets in single IP |
| GNSS | GPS, GAGAN, QZSS, BeiDou |
| Channels | 32 tracking channels, 96 capture channels, 210 PRN channels |
| Horizontal Position Autonomous | < 2.5m CEP |
| SBAS | Supported |
| 2 DRMS, Vertical | ± 5m |
| Tracking Sensitivity | -158 dBm |
| Re acquisition Sensitivity | -156 dBm |
| Velocity | 0.1m/s |
| Hot Start | <1 sec |
| Warm Start | < 10 sec |
| Cold Start | < 35 sec |
| Technology | GSM |
| 2G Band | 850/900/1800/1900 MHz |
| RF Power | Class 4 (2W@850/900MHz), Class 1 (1W@1800/1900MHz) |
| Coding Scheme | CS 1,2,3,4 |
| SMS | Text |
| Voltage Range | 9-90V DC |
| Battery | 260 mAh Li-Po 3.7V |
| Specification | BLE 5.0 |
| Working Current | Sleep Mode < 25mA, Active Mode < 180mA |
| Operating Temperature | -20 °C to +60 °C (With Battery), -30 °C to +75 °C (Without Battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Ingress Protection Rating | IP54 |
| Dimensions | 88x45x15 mm (LxBxH) |
| Weight | 105 g |
| Sensors | Accelerometer |
| Scenarios | Overspeeding, DOUT, Unplug detection, Rash Driving |
| Sleep modes | Deep Sleep |
| Configuration and firmware update | FOTA Web, FOTA |
| SMS | Configuration, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time Synchronization | GPS |
